TELLMon remote monitoring receiver (Ethernet)

Remote monitoring IP-receiver that enables receiving signals from SIA IP-communicators.

More details about the product

Additional product versions

Remote monitoring IP-receiver that enables receiving signals from SIA IP-communicators.

Standalone remote monitoring IP receiver based on the custom
TELLMon protocol
Supported communication protocols: TELLMon, TEX, SIA DC-09 (ADM-CID, SIA-DCS)
Optional 3G or 4G modem (direct connection with communicators through private APN)
Reliable and stable Linux-based operating system
Data transfer function over serial port: when being fitted into an existing system, the TELLMon is capable of forwarding the communication of other connected receivers towards the alarm monitoring software (transparent data forwarding)
Simple and clear graphical interface, which can be accessed remotely for configuration and monitoring as well
Can receive reports from up to 2000 communicators simultaneously
Compact, quiet, durable, with low power consumption
Operator interface (dispatcher feature)
Customer management
Supported operating system: Windows 10

Application area:

Identifiers

Additional product versions:

TELLMon

Technical specification

Supply voltage:

230 VAC / 12 VDC

Dimensions:

190x218x64 mm

Package size:

307x277x116 mm

Product weight:

1,5 kg

Weight (with package):

2,15 kg

Vételi opciók

4G connection:

Optional

Forwards received signals through local RS232 port:

Yes

Signal reception via IP:

Yes

Receives signals from TELL GPRS communicators with unique (TEX) protocol:

Yes

Receives signals from TELL SIA IP communicators:

Yes

Weight:

2.15 kg/db
